Electromagnetic Hold Open Door Closer without arm - Silver

Electromagnetic Hold Open Door Closer without arm - Silver

SKU: TS4000E

The GEZE TS4000E EN1-6 Hold Open Electromagnetic Door Closer is a surface mounted rack and pinion door closer with electro-hydraulic hold-open device for single action right and left hand closing doors up to 1400mm wide. TS4000 E (24 V DC) overhead d… Read More

Key Features
  • For single-action doors, leaf width up to 1400 mm
  • Adjustable Power Size EN 1-6
  • Suitable for doors up to 120kg
  • Compatible with left-hand and right-hand doors without the need for conversion
  • 24V DC 45mA operating voltage – Low Power Consumption
  • For fire protection doors (door closers with mounting plate)
  • 120 minute fire rating
  • Suitable for Pull Side (Fig 1) Mounting
  • Transom Mounted (Fig 61) available upon request
  • Other Finishes are also available upon request

In Stock

Description

The GEZE TS4000E EN1-6 Hold Open Electromagnetic Door Closer is a surface mounted rack and pinion door closer with electro-hydraulic hold-open device for single action right and left hand closing doors up to 1400mm wide. TS4000 E (24 V DC) overhead door closer, features an electric hold-open between 80° and 180° in accordance with EN 1155, is approved for use with left and right single-action doors with a door leaf width up to 1400 mm and for mounting on fire and smoke protection doors. In the event of a fire alarm activation or power failure, the GEZE TS4000E hold-open mechanism is deactivated and the door closes securely, just like a manual door closer. The variable Power Size EN 1-6 closing force to EN 1154, with optical size indicator, and the thermoconstant closing speed can be conveniently and easily adjusted from the front; the latching action is adjusted by means of the link arm.

Download

TS4000E.pdf
