Round-LED Mains only IP65 circular bulkhead with Dali driver

Description

The Round-LED range provides both mains and emergency lighting from a well-designed luminaire with a white polycarbonate base and opal polycarbonate diffuser, sealed to IP65, making it suitable for both interior and external applications. The luminaire has a unique lever to release the diffuser which can be secured with the supplied locking screw to increase tamper/vandal resistance. Internally, the removable steel gear tray has 54 white high output long life LEDs mounted upon it reveals access to the control gear and terminal blocks. The Round-LED range supports all the features of the Lux Intelligent range of emergency lighting test panels and also fully complies with the requirements of EN60598.2.22. It also meets with the current Part L energy targets offering over 60 lumens per Watt. The luminaire can be supplied in both mains only or maintained emergency versions (non-maintained can be achieved by excluding the normal switched mains live supply). Both versions can be supplied with dimming control as well microwave presence detectors. All emergency versions provide 3-hour duration from the integral high temperature (NiMH) batteries. Maintained versions can be used for standard switched mains lighting but will automatically provide emergency lighting in the event of a complete loss of local mains supply.
