Hochiki Mains Relay Controller DIN Encl. SCI

SKU: CHQ-MRC2/DIN(SCI)

Key Features

Loop-powered
Single loop address
Single mains rated relay contact
Relay contact rated at 250 Vac @ 5 A (resistive load only) & 48Vdc @ 2 A (resistive load only)
Auxiliary monitored input
DIN rail version available
Both models feature an integral short-circuit isolator

Description
Downloads

Description

Model CHQ-MRC/DIN(SCI) is a Single Input/Output Module, which provides a single, mains-rated relay output for the control of such devices as dampers, extractors or plant and equipment shutdown. The monitored input can be used for local power supply fault monitoring or as a general-purpose input. The unit is supplied as a DIN Rail mountable version but is also available as a boxed module. Both models feature an integral short-circuit isolator. The CHQ-MRC/DIN(SCI) utilises simple DIL switches for reliable addressing.
